The 645Z Medium Format DSLR Camera (Body Only) from Pentax features a 43.8 x 32.8 mm CMOS sensor with 51.4 effective megapixels. The sensor is designed without an anti-aliasing filter to maximize sharpness and details. RAW files can be recorded at 14-bit and saved using either the proprietary PEF format or Adobe's DNG format. An ISO range from 100-204,800 and high S/N ratio provides low noise, low light capability, and the Prime III image processor lends itself to fast image capture with a maximum of 3 fps continuous shooting. The SAFOX II autofocus module utilizes 27 autofocus points including 25 cross-type sensors and 3 AF sensors dedicated for low light focusing. The new Real Time Scene Analysis System features an 86,000 pixel RGB light-metering sensor for enhanced accuracy of exposure, white balance, and auto-focusing. Full HD 1080 60i/30p/24p video capture is supported in the H.264 format with a dedicated button for instant switchover from stills to video. An external microphone jack enables high quality audio recording with manual sound level control and monitoring. An HDMI port outputs HD images to HDTVs and a USB 3.0 jack enables fast image transfer to your computer. Interval recording for time-lapse videos is supported with an output of UHD 4K resolution. A 3.2", 1037k-dot, tilting, air-gapless, LCD monitor enables live view composition and playback viewing from a various angles and a trapezoid-shaped glass prism viewfinder with Kepler telescope-type eyepiece unit provides traditional eye-level composition. The design of the viewfinder also helps to achieve the relatively compact size of this medium format camera. The 645Z is extremely durable with an aluminum alloy chassis, magnesium alloy shell, and 76 specific weather seals to keep out moisture and dust. It is a camera designed for field as well as studio and can operate in temperatures from 14-104°F. The camera body also features a deep set ergonomic grip, ideal for hand-held shooting, easy-to-access buttons, and a top-plate, sub-LCD screen that is angled up for easier visibility of camera information. A hot shoe mount is supported, and in addition to the tripod socket on the camera's base, a second tripod socket is located on the side of the camera for convenient and stable tripod shooting in the vertical position. Two SD slots are provided for versatile image storage and both Flucards and Eye-Fi cards are compatible for wireless image transfer. The optional Pentax Image Transmitter 2 software along with the USB 3.0 output enable seamless and fast tethered shooting. The 645Z is compatible with the new FA autofocus lenses as well as older 645 lenses and with Pentax 67 medium format lenses when used with an adapter.
645Z Body KitCAMERA HARDWAREMODEL: 645ZTYPE: TTL autofocus, auto-exposure medium format digital SLR cameraSENSORType: CMOS w/ primary color filterSize: 43.8 x 32.8 (mm)Color depth: 8 bits/channel JPG, 14 bits/channel RAWEffective pixels: 51.40 MPTotal pixels: 52.99 MPStill resolution:JPEG: L (51M: 8256 x 6192), M (36M: 6912 x 5184), S (21M: 5376 x 4032), XS (3M: 1920 x 1440)RAW: L (51M: 8256 x 6192)TIFF: L (51M: 8256 x 6192)Quality Levels: JPEG: * * * (Best), * * (Better), * (Good)RAW and JPEG simultaneously recording available, RAW (14-bit): PEF, DNG Movie (resolution/FPS):Full HD (1920x1080, 60i/50i/30p/25p/24p), HD (1280x720, 60p/50p/30p/25p/24p)Dust Removal: Image sensor cleaning using ultrasonic vibrations "DR II" with the Dust Alert functionLENS MOUNTType/construction: PENTAX 645AF2 mount with AF coupler, lens information contacts, and power contacts (stainless steel)Usable lenses: PENTAX 645AF2, 645AF and 645A mount lenses (PENTAX 67 medium format lenses useable with adapter), SDM function: YesFOCUS SYSTEMType: SAFOX 11 TTL phase-matching autofocus with 27 AF points (25 cross type focus points in the center)AF modes: Single AF (AF.S), Continuous AF (AF.C), Focus operation customizable, Manual Focus Area Selection Modes: Spot, Select, Expanded Area AF (S, M, L), Zone Select, Auto (27 AF Points)Brightness Range: EV -3 to 18 (ISO 100-204,800, at normal temperature)VIEWFINDERType: Keplerian telescopic trapezoid prism finderCoverage (field of view): Approx. 98%Magnification: Approx. 0.62 x (55mmF2.8 at infinity), Approx. 0.85 x (75mmF2.8 at infinity)Standard focusing screen: Interchangeable Natural-Bright-Matte focusing screenDiopter adjustment: Approx. -3.5 m to + 2.0 m-1Depth of field preview: Optical (diaphragm stop-down), DigitalEye-relief length: Approx. 21 mm (from view window), Approx 24.1 mm (from center of lens)LCD MONITORType: 3.2" Tiltable TFT color LCD monitor featuring an air-gapless structure with an AR-coated, tempered-glass front panel and brightness/saturation/color adjustmentsResolution: Approx. 1037K dotsWide angle viewable: YesLIVE VIEWType: TTL using CMOS image sensorField Of View: approx.100%Display Modes: Magnified view (2x, 4x, 8x, 12x, 16x), Grid Display (Grid Style: 4x4 Grid, Golden Section, Scale, Square 1, Square 2, Grid Color: translucent black, translucent white), Histogram, Highlight Alert, Rotate Display 180°Autofocus: Contrast detection AF (Face Detection, Tracking, Multiple AF Points, Select, Spot), Focus Peaking: ON/OFFEXTERNAL FLASH (using PENTAX dedicated external flash)Type: Hotshoe (P-TTL), high speed sync and wireless w PENTAX dedicated flash, X-Sync Socket Flash Modes: Flash On, Flash On+Red-eye Reduction, Slow-speed Sync, Slow-speed Sync+Red-eye, P-TTL, Trailing Curtain Sync, contrast-control-sync, high-speed sync, wireless sync (available with a dedicated external flash)Flash exposure compensation: -2 to +1 EV (1/2 steps)Synchronization speed: 1/125 secSTORAGE MEDIARemovable memory: SD, SDHC*, SDXC* memory card, Eye-Fi card, FLUCARD *UHS-I compatible Dual Card Slot: Sequential save, Save to Both Dual save, Separate RAW/JPG, Copying images between slots possibleINTERFACESConnection Ports: USB 3.0 (micro B), external power supply terminal, cable switch terminal, X-sync socket, HDMI output terminal (Type D), stereo microphone input terminal (USB Connection: MSC/PTP)Video out: HD (via HDMI), NTSC, PALPOWER SUPPLYBattery Type: Rechargeable Li-Ion battery D-LI90Number of recordable images: Approx. 650Playback time: Approx. 400 minMovie recording time: Up to 25 minutes; automatically stops recording if the internal temperature of the camera becomes high.AC adapter available: AC Adapter Kit K-AC132 (Optional)PHYSICAL SPECIFICATIONSBody dimensions (W x H x D): 6.14in x 4.6in x 4.84in (excluding protrusions)Body weight: Approx. 54.67oz (including battery and memory card)Body only: Approx. 51.85ozConstruction material(s): Magnesium alloy shell over aluminum chassisWeather resistant: Yes (76 special seals)Operating temperature: 14-104°F (-10° to 40°C)LANGUAGE SUPPORTEnglish, French, Germany, Spanish, Portuguese, Italian, Dutch, Danish, Swedish, Finnish, Polish, Czech, Hungarian, Turkish, Greek, Russian, Korean, Traditional Chinese, Simplified Chinese, JapaneseFILE STORAGE MATRIX (BASED ON 8GB MEMORY)File Storage Matrix (Based on 4GB Memory, 4:3 Aspect Ratio)| JPG | RAW PEF/DNG | TIFF | Jpeg * * * | Jpeg * * | Jpeg * |
|---|
| L: 51MB | 71/71 | 48 | 211 | 480 | 972 | | M: 36MB | | | 300 | 682 | 1349 | | S: 21MB | | | 495 | 1121 | 2193 | | XS: 3MB | | | 3665 | 7675 | 13645 | | MOVIE (H:M:S) | 1920 x 1080 | | | 1280 x 720 | |
|---|
| 60i | 00:32:15 | | | 60p | 00:32:15 | | 50i | 00:38:21 | | | 50p | 00:38:21 | | 30p | 00:32:15 | | | 30p | 00:54:36 | | 25p | 00:38:21 | | | 25p | 01:04:31 | | 24p | 00:39:51 | | | 24p | 01:06:57 | COMPUTER SYSTEM REQUIREMENTS (OS)*Windows: Windows 8.1 (32 bit/64 bit) / Windows 8 (32 bit/64 bit) / Windows 7 (32 bit/64 bit) / Windows Vista (32 bit/64 bit), Intel Core 2 Quad or higher, 4GB or more Mac: Mac OS X 10.9 /10.8 / 10.7 / 10.6, Intel Core 2 Quad or higher, 4GB or more IMAGE CAPTUREIMAGE STABILIZATIONType: Lens-shift type (When using SR system lens)METERING SYSTEMType: TTL open aperture metering using 86K pixel RGB sensorSensitivity range: EV -1 to 21 (ISO 100-204,800 at 55mmF2.8)Metering Modes: Multi-segment metering, Center-weighted metering, Spot meteringExposure compensation: ±5 EV (1/3 EV steps or 1/2 EV steps can be selected)AE Lock: Button type (timer-control: two times the meter operating time set in Custom Setting), Continuous as long as the shutter release button is depressed halfwayExposure bracketing: 2, 3 or 5 frames, Available with Continuous, Self-timer or Remote ControlISO SENSITIVITYISO AUTO/100 to 204,800 (EV steps can be set to 1EV, 1/2EV, or 1/3EV)WHITE BALANCEType: system combining CMOS image and light source detection sensorsAuto, Multi Auto, Daylight, Shade, Cloudy, Fluorescent Light (D: Daylight Color, N: Daylight White, W: Cool White, L: Warm White), Tungsten, Flash, CTEManual mode(s): Manual (up to 3 settings can be saved), Color Temperature (up to 3 settings can be saved), Copying the white balance settings of a captured image possibleSHUTTERType: Electronically controlled vertical-run focal plane shutterShutter speed: Auto: 1/4000 to 30 sec., Manual: 1/4000 to 30 sec. (1/3 EV steps or 1/2 EV steps), BulbCAPTURE MODESExposure modes: Program, Sensitivity Priority, Shutter Priority, Aperture Priority, Shutter & Aperture Priority, Manual, Bulb, Flash X-sync Speed, USER1, USER2, USER3Custom Image: Bright, Natural, Portrait, Landscape, Vibrant, Radiant, Muted, Bleach Bypass, Reversal Film, Monochrome, Cross Processing (Random, Preset 1-3, Favorite 1-3)HDR Capture: Auto, Type1, Type2, Type3, Exposure Bracket Value adjustable, Auto Align (automatic composition correction function) availableNoise Reduction: Slow Shutter Speed NR, High-ISO NRDynamic Range Settings: Highlight Correction, Shadow CorrectionLens Correction: Distortion Correction, Lateral Chromatic Aberration Correction, Peripheral Illumination Correction, Diffraction CorrectionElectronic Level: Displayed in viewfinder and LCD panel (horizontal direction only); displayed on LCD monitor (horizontal direction and vertical direction)Data record: Folder Name: Date (100_1018, 101_1019…) or user-assigned (default: PENTX) embed copyright. Date stamp: n/a.DRIVE MODESMode selection: Stills: Single Frame, Continuous (H, L), Self-timer (12 sec., 2sec.), Remote Control (immediately, 3 sec., continuous), Multi-exposure (available with Continuous, Self-timer or Remote Control), Interval Shooting, Interval CompositeMovie: Remote Control, Interval Movie RecordMulti-exposure: Composite Mode (Additive/Average/Bright) Number of Shots (2 to 2000 images), Interval 2000 shots, 2 sec to 24 hrs, time delay available)*Continuous shooting: Max approx. 3 fps, JPEG ( L: * * * at Continuous H): up to approx. 30 frames, RAW: up to approx. 10 frames, TIFF: up to approx. 12*Continuous shooting: Max. approx. 1 fps, JPEG (L: * * * at Continuous L): up to approx. 300 frames, RAW: up to approx. 25 frames, TIFF: up to approx. 15*When the sensitivity is set to ISO100Self-timer: Yes (12s, 2s)Remote control: Yes, infrared (0s, 3s, continuous), cable switchPLAYBACK MODESPlayback view: Single image display, Multi-image display (6, 12, 20, 35, 80 thumbnails), Image magnification (up to 16x, 1x display and quick zoom available), Grid Display (Grid Style: 4x4 Grid, Golden Section, Scale, Square 1, Square 2, Grid Color: translucent black, translucent white), Rotated image display, Histogram (Y histogram, RGB histogram), Highlight Alert, Auto Image Rotation, Detailed Information Display, Copyright Information (Photographer, Copyright Holder), Folder Display, Calendar Filmstrip Display, Slideshow, *GPS information (latitude, longitude, altitude, Coordinated Universal Time (UTC)), *with optional O-GPS1 unitDigital filters (playback): Base Parameter Adj, Extract Color, Toy Camera, Retro, High Contrast, Shading, Invert Color, Unicolor Bold, Bold Monochrome, Tone Expansion, Sketch, Water Color, Pastel, Posterization, Miniature, Soft, Starburst, Fish-eye, SlimRAW Development: Select single image, Select multiple images, Select a folderDevelopment parameters: File Format (JPEG/TIFF), Aspect Ratio, JPEG Recorded Pixels, JPEG Quality, Color Space, Distortion Correction, Lateral Chromatic Aberration Correction, Peripheral Illumination Correction, Diffraction Correction, Color Fringe Correction, White Balance, Custom Image, Digital Filter, HDR, Sensitivity, High-ISO NR, Shadow CorrectionFILE FORMATSStill: RAW (PEF/DNG), TIFF, JPEG (Exif 2.30), DCF2.0 compliantMovie: MPEG-4 AVC/H.264 (MOV) *Motion JPEG (AVI) for Interval Movie Record
645Z Body KitLi-ion Battery D-Li90 (E)Battery Charger Kit K-BC90Strap O-ST150Large Eye Cup O-EC107Software CD-ROM S-SW150Standard eyecup 645, Hot shoe cover FK, Sync socket 2p cap, Body mount cap 645, Triangular ring and protective cover (Installed on camera)
|
